Hot Mounting Press
Product Details:
- Product Type Hot Mounting
- Power Source Other
- Operating Type Automatic
- Power 1000 Watt (w)
- Surface Treatment Galvanized
- Dimension (L*W*H) 340 x 270 x 400 Millimeter (mm)
- Click to view more
Hot Mounting Press Price And Quantity
- 1 Piece
Hot Mounting Press Product Specifications
- 1000 Watt (w)
- Automatic
- 340 x 270 x 400 Millimeter (mm)
- Galvanized
- Hot Mounting
- Other
Hot Mounting Press Trade Information
- 10 Piece Per Month
- 1 Days
- All India
Product Description
It is suitable for the heat mounting(thermo hardening & thermoplastic) for all kinds of materials. After the parameters such as heating temperature, heat preserving time and applied force etc. are set up, put the specimen and mounting material into the machine, close the cover and press the start button, then the machine will finish the job automatically.
It is not necessary for the operator to be on duty. According to different requirements of the material, there are four kinds of moulds that can be chosen to meet the demands at will. Also it is available to prepare two pieces of specimens at the same time, the capacity is doubled.
Technical Specifications:
| Model | BETAMON-5 |
| Diameter of specimen | ˜25mm, ˜30mm, 40mm, ˜50mm |
| Power supply | single phase, 220V, 50Hz |
| Max. power consumption | 1600W |
| Setting range of system pressure intensity | 0-2MPa (corresponding preparing pressure intensity: 0-72MPa) |
| Temperature setting range | 0-180 ºC |
| Heat preserving time | 0-99m99s |
| Net weight | Approx. 82kg |
